48V5KW

72V4KW

电池

BATTERY

铅酸电池，48V150AH（9.6度）Lithium iron phosphate battery, Guosheng 48V200AH (9.6 KWH)

磷酸铁锂电池，72V140AH（10度）Lithium iron phosphate battery, Guosheng 72V140AH (10KWH)

电机                    MOTOR

马勒,48V5KW交流

MAHLE 48V5KW A/C

马勒,72V4KW交流

MAHLE 72V4KW A/C

控制器总成                     CONTROLLER

ACMII CURTIS    48C350AH

柯蒂斯    48C350AH

ACMII CURTIS    72C450AH

柯蒂斯嘉晨    72C450AH

DC-DC 转换器总成

DC INVERTOR

CURTIS    350A

柯蒂斯 350A

CURTIS    450A

柯蒂斯 450A

后桥总成

rear axle assembly

零越，端面距958.8mm,板簧距660.3mm,圆法兰，19齿，刹车盘直径160mm，分布圆为4-φ101.6mm                          Lingyue Brand, end face distance 958.8mm, leaf spring distance   660.3mm, round flange, 19 teeth, brake disc diameter 160mm, distribution   circle 4-φ101.6mm

制动系统                 Brake sysytem

油刹、前碟后鼓                                                     Oil brake, front disc and rear drum

底盘材质

高强度碳钢焊接+酸洗磷化+喷塑

悬挂系统                Suspension system

A字臂前独立悬挂；后纵置板簧+阻尼器                          Front A arm independent suspension; rear longitudinal leaf spring +   damper

仪表台                         Dashband

仿皮纹多功能汽车仪表台                                              Multifunctional car dashboard

功能开关function switch

高级翘板开关Advanced Rocker Switches

USB系统USB system

USB2.0、3.0，支持U盘外接输入音频MP3、视频等USB2.0,   3.0, support U disk external input audio MP3, video, etc.

点烟器插座

cigarette lighter socket

12V电源输出

12V power output

中控显示console display

10.1寸多媒体大屏；lINUX系统                            10.1-inch multimedia screen; LINUX system

中控屏功能                Central control screen   function

车辆检测功能（车速、电量、电压等）                          Vehicle detection   function (vehicle speed, power, voltage, etc.)

多媒体功能（通信录、收音机、手机蓝牙互联及投屏、视频、音乐、多国语言等）

音响系统                   sound system

Hasda汽车音响*2                                      Hasda   Car Audio*2

杯座                        cup holder

左右可抽拔式杯座各两个                                       Two   removable cup holders on the left and right

储物箱                     storage box

隐藏式储物箱左右各一个，带钥匙锁开合式面板                    Hidden storage   compartments, one left and one left, with key lock opening and closing panels

中控置物                    central storage

斜坡式置物格（可加球座及无线充电系统）                   Slope storage compartment   (can add tee and wireless charging system

前大灯                       Headlight

近光、远光、转向、带日间行车灯功能                           Low beam, high   beam, steering, with daytime running lights

后大灯                     Taillight

转向、刹车Steering, Braking

轮胎、轮毂                       tires, Hub Rim

205-40-14；235-30-14

左右后视镜

带电子转向灯

安全带                 safety seatbelt

twin point MG    steel toughed springs

座椅坐垫Seat and Cushion

一体成型仿皮座椅                                      Synthetic leather   seat

翻转式折叠座椅flip-flops

底座材料（PP工程塑料）；一体成型仿皮座椅+储物冰箱                                        Synthetic leather seat flip-flops

中网 Front Grill

按客人需求定做Customized as per customer's   design

车辆尺寸Vehicle Size

3855*1150*2000
